Overview
The Occupant Restraint Indicator module works in conjunction with the 6444 Series Vehicle Data Recorder to indicate passenger location and safety equipment status to the driver per NFPA 1901 requirements. The 6204 indicator includes audible and visual warning of unsafe occupant conditions. The Occupant Restraint Indicator works with your vehicle’s V-MUX multiplexing system utilizing the Vista display.
Features
The ORI offers real time feedback on seat status so a driver can visually see when their passengers are seated and buckled.
- Display seat status in red, green
- Beep when there is a seat violation
- Display is dimmable for night time use
- Output for additional buzzer or warning indicator
SEATBELT INDICATOR MODULE(AB)
Technical details & documents
For the SEATBELT INDICATOR MODULE(AB)
To view all documents login to your account
Specification
| Style | 6204-0000-00 |
|---|---|
| Certifications | NFPA 1964 |
| Family | Displays |
| Brand | Weldon |
| Inventory Type | Finished Good |
| Engine Power | 0.00 HP |
Drawings
Installation & Service
Documents
| Name | Last Modified | Sheet # | |
|---|---|---|---|
|
6204 Seat Indicator Module Installation Drawing 92.88 kB |
2009-04-17 | Download | |
|
V-MUX Connector Parts and Specs 3.61 MB |
2020-03-14 | Download |
Need assistance with service or installation? Find a dealer
near you or contact our Technical Support Team
