Overview
Features
-Instant-on lighting -Patented Diamondback styling complements warning lamps -Very high optical efficiency maximizes illumination with minimal power consumption -High precision optical elements direct light onto work surfaces; integral "tilt-down" -Efficient electronics reduce current draw and provide stable light intensity from 11-32VDC -Better light output than 50W halogen at 1/2 the power -High-Impact polycarbonate lens with anti-scratch hard coating -Fully serviceable/upgradeable components -Integral mounting pad -Optional chrome bezel kit with mounting pad -5 year warranty
DIAMONDBACK, 7X9, SCENE, WHITE
Technical details & documents
For the DIAMONDBACK, 7X9, SCENE, WHITE
To view all documents login to your account
| Style | V79S |
|---|---|
| Certifications | NFPA 1964 |
| Brand | Weldon |
| Product or Spare Part | Finished Good |
| Volts | 10-32VDC |
| Warranty | 5 year |
| wattage | 24 |
| Width (English) | 9.12 in |
| Width (Metric) | 232 mm |
| Depth (English) | 1.51 in |
| Depth (Metric) | 38.3 mm |
| Height (English) | 7.11 in |
| Height (Metric) | 181 mm |
| Amperage | 1.84 |
| Engine Power | 0.00 HP |
| Lamp Size | 7''x9'' |
| Lamp Source | LED |
| Name | Last Modified | |
|---|---|---|
|
Quality Assurance Notification for Equipment and Protective Systems Intended for us in Potentially Explosive Atmospheres Directive (ATEX) 107.28 kB |
2025-02-14 | Download |
| Name | Last Modified | |
|---|---|---|
|
V79 Series Diamondback Lamp C-Drawing 98.53 kB |
2025-02-14 | Download |
| Name | Last Modified | |
|---|---|---|
|
Style ELBE, 55" Tripod dimensions" 103.49 kB |
2025-02-14 | Download |
|
IR Programming Instructions 520.02 kB |
2025-02-14 | Download |
