Overview
Features
The UltraView™ 500 display features a freely configurable design allowing custom software to be quickly developed. The display is compatible with PowerVision Configuration Studio® and V-Mux DTD software to enable quick and easy changes to the programming. The highly durable display features a full-color, robust 5-inch bonded, touch, LCD for best-in-class sunlight readability. The UV500’s rugged design makes it a great solution for all types of environments and applications.
UV500
- Product code:
- 610-00060-050
- Availability:
-
Available | Delivery in 25 Days
- Applications:
- Bus & Pupil Transportation, Commercial Trucks, Defense & Homeland Security, Deicing, Emergency Responder OEMs, Engineered Solutions, Equipment and Tank Washing, Fire OEMs, Firefighting - Airport (ARFF), Firefighting - Industrial, Firefighting - Structural, Firefighting - Wildland Forestry, Law Enforcement, Marine, Mining, Petro-Chemical, Rescue - EMS, Rescue - Hazardous Materials (HazMat), Specialty Vehicles, Police/Law Enforcement OEMs
Technical details & documents
For the UV500
To view all documents login to your account
| Style | 610-00060 Ultra View |
|---|---|
| Can Specification | SAE J1939, CANOpen |
| Certifications | CE |
| Brand | Weldon |
| Application Solutions | Bus & Pupil Transportation, Commercial Trucks, Defense & Homeland Security, Deicing, Emergency Responder OEMs, Engineered Solutions, Equipment and Tank Washing, Fire OEMs, Firefighting - Airport (ARFF), Firefighting - Industrial, Firefighting - Structural, Firefighting - Wildland Forestry, Law Enforcement, Marine, Mining, Petro-Chemical, Rescue - EMS, Rescue - Hazardous Materials (HazMat), Specialty Vehicles, Police/Law Enforcement OEMs |
| Product or Spare Part | Finished Good |
| Environmental Range | IP 66, 67 |
| Volts | +12 VDC ... +32 VDC |
| Width (English) | 7.356" |
| Width (Metric) | 186.84 mm |
| NFPA 1960 2024 Compliant | No |
| Depth (English) | 1.944" |
| Depth (Metric) | 49.40 mm |
| Height (English) | 3.79" |
| Height (Metric) | 96.5 mm |
| Engine Power | 0.00 HP |
Operating Temperature
- -40C ... +85C
Display
- Bonded 4.3” color transmissive TFT LCD
Resolution
- WQVGA, 480 x 272 pixels, 16-bit color
Aspect Ratio
- 16:9
Orientation
- Landscape or portrait
Backlighting
- LED, 500-650 cd/m2 (30,000 hr lifetime)
Microprocessor
- Freescale i.MX357 32bit, 532Mhz QNX Realtime Operating System
Flash Memory
- 256 MB
RAM
- 128 Mbytes DDR2 SDRAM
Power Consumption
- 10W max. (CSA, 163 mA max @ 30VDC)
CAN
- (2) CAN 2.0B; optional NMEA 2000 isolation, isolation with HVS450
Protocols
- J1939, NMEA 2000, CAN open
RS-485
- (1) MODBUS Master/Slave
Video Input (Optional)
- (2) NTSC/PAL input channels with one displayed at a time
Connection
- (4) Deutsch DT 6-pin connectors
Keyboard
- (8) tactile buttons with white LED backlight
USB
- 2.0 host, full speed
Clock
- Real time clock with built-in rechargeable Li-ion battery backup (0.033 mWh)
Electromagnetic Compatibility
- 2004/108/EC EN 60945:2002
- EN 61000-6-4 EN 50121-3-2
- EN 61000-6-2 (immunity) EN 12895
- J1113/2, 4, 11, 12, 21, 24, 26 and 41
Vibration
- Random vibration, 7.86 Grms (5-2000 Hz), 3 axes
Shock
- ± 50G in 3 axes
