Overview
Non-locking heavy-duty valve with a stainless steel ball designed for the harsh realities of today's fire service when water contaminants challenge a valve's sealing capabilities. This valve features the following:
- A single valve body that will accept a variety of actuators
- HydroMax TM technology: A patented ball geometry providing performance never seen before in swing-out valves
Actuator options:
- Manual Gear
- Electric Actuator
- R/S
- SZ
Actuator/handle and adapters not included in price.
Request a quote on this valve and other apparatus valves today.
Features
- 3" waterway
- Non-Locking valve
- 316 stainless steel ball for longer valve life
- High quality brass body
- Improve sealing & increased gating ability
- Flow optimization reduces turbulence while in the gated position and requires lower operating forces
- No lubrication or regular maintenance required
- Simple two-seated design (no O-Rings to cut or lose during assembly or maintenance)
- Wide range of available adapters
- Designed and tested to exceed NFPA requirements
- Cast, machined and assembled at our facilities in Wooster, Ohio
Actuator options:
- Manual Gear
- Electric Actuator
- R/S
- SZ Adapters specified separately. See valve guide for complete list of available adapters.
Actuator/handle and adapters not included in price.
3" Generation II Swing-Out Valve (Body Only) with stainless ball
Technical details & documents
For the 3" Generation II Swing-Out Valve (Body Only) with stainless ball
To view all documents login to your account
| Style | 8630 |
|---|---|
| Family | Apparatus |
| Brand | Akron Brass |
| Application Solutions | Fire OEMs |
| Material | Brass |
| Product or Spare Part | Finished Good |
| Finish | Cast Brass |
| Volts | 12 V DC or 24 V DC |
| Warranty | 10 Year |
| Water Size (English) | 3" |
| Water Size (Metric) | 75 mm |
| Length (English) | 4'' |
| Length (Metric) | 102 mm |
| Engine Power | 0.00 HP |
| Name | Last Modified | |
|---|---|---|
|
Style 8620 - 8635 Gear Actuator Parts List 1.08 MB |
2025-11-10 | Download |
|
Style 8620 - 8635 Parts list - Position indicator 641.26 kB |
2025-03-12 | Download |
|
Gear Actuator - Installation & Operational Instructions 88.99 kB |
2025-04-22 | Download |
|
Style 8600,7900 & 8900 Parts List - Electric Actuator Subassemblies 4.19 MB |
2025-04-15 | Download |
|
Electric Actuator Assembly Parts List (mfg. after April 2020) 3.76 MB |
2025-11-07 | Download |
|
Style 8615-8635 Parts List – Generation II Swing-Out valve with Electric Actuator (Mfg. after April 2020) 2.09 MB |
2025-08-06 | Download |
|
Style 9206 Service Kit Instructions 191.39 kB |
2025-03-07 | Download |
|
Ball Valve Position Indicator - Installation Instructions & Parts List 93.97 kB |
2025-03-12 | Download |
|
Valve Guide 7.60 MB |
2025-02-14 | Download |
